Steel/Fiberglass Hand Pump Air Powered Stacker with Adjustable Forks and Legs 63 In. Raised Height 2,000 Lb. Capacity Black / Yellow

Pneumatic Adjustable Hydraulic Hand Pump Stacker for Moving Loads Through Warehouses and Production Areas, 2,000 lb. Capacity with 63 in. Raised Height
An economical alternative air powered lift stacker. Ideal for maintenance and commercial applications. Compact design and strong steel construction. An economical lift to handle tasks such as transporting dies, molds, and skids. Requires 80-100 psi factory air supply for operation. All models are easily maneuverable using the standard pull handle. Forks measures 26." wide by 42" long. Individual forks are 6" wide.
Product Status
Temporarily Unavailable - Please Contact Sales Non-Returnable
Key Features
  • Adjustable forks to meet users needs
  • Air powered operation
  • Robust capacity for heavy loads
  • Precise positioning capabilities
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Documents

PDFs & Product Files

  SE/HP Series Combination Hand Pump and Electric Stackers Instruction Manual   Label Page PDF   1 Year Warranty
Product Data

Core Data

Assembled Weight 780 lbs
Assembled Size 48"W x 63.5"L x 79"H
Total Ship Weight 958 lbs
Package 1 Size 60"W x 64"D x 84"H
Color / Finish Black / Yellow
Freight Type LTL Palletized

Additional Attributes

Uniform Capacity (lb.) 2,000
Adjustable Fork Spacing (in.) 8-3/8 to 26-3/4 (OD)
Fork Width/Length (in.) 4 x 42
Service Range (in.) 2-9/16 to 63
Adjustable Leg Spacing (in.) 40-1/8 to 50 (ID)
Overall Mast Height (in.) 78-5/8
Required PSI 80-100
Extended Product Details

Marketing Specs.

MFG Model # (Series)
SE/HP-63-AA-AIR
Product Name
Steel/Fiberglass Hand Pump Air Powered Stacker with Adjustable Forks and Legs 63 In. Raised Height 2,000 Lb. Capacity Black / Yellow
UPC
691215230841
GTIN
00691215230841
Taxonomy 1
Material Handling
Taxonomy 2
Lifting Equipment
Taxonomy 3
Lifters / tilters
Taxonomy 4
Box Stacker
Taxonomy 5
Manual
Assembled Depth (in.)
63.5
Assembled Width(in.)
48
Assembled Height(in.)
79
Assembled Weight(lbs.)
780
Color/Finish
Black / Yellow
Material
Steel/Fiberglass
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
CN
Approval Drawing Required? Y/N
Y
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
64
Package Width (in.)
60
Package Height (in.)
84
Package Weight (in.)
958
Subclass
1
Freight Class
175
NMFC Code
Lift trucks hand including pallet jacks
NMFC Number
189240
LTL Freight
LTL Palletized
UNSPSC
24101606
HTSUS Number
8428.90.0390
USMCA HS
8428.90
Origin Criterion
NO
Certification Indicator
NO
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
1 Year Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
N
Returnable? Y/N
N
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: SE/HP-63-AA-AIR

SE/HP-63-AA-AIR

Steel/Fiberglass Hand Pump Air Powered Stacker with Adjustable Forks and Legs 63 In. Raised Height 2,000 Lb. Capacity Black / Yellow

An economical alternative air powered lift stacker. Ideal for maintenance and commercial applications. Compact design and strong steel construction. An economical lift to handle tasks such as transporting dies, molds, and skids. Requires 80-100 psi factory air supply for operation. All models are easily maneuverable using the standard pull handle. Forks measures 26." wide by 42" long. Individual forks are 6" wide.

  • Adjustable forks to meet users needs
  • Air powered operation
  • Robust capacity for heavy loads
  • Precise positioning capabilities

Core Data

Assembled Weight: 780 Assembled Size: 48"W x 63.5"L x 79"H Color: Black / Yellow
Total Ship Weight: 958 Package 1 Size: 60"W x 64"D x 84"H Freight: LTL Palletized

Specifications

Uniform Capacity (lb.): 2,000
Adjustable Fork Spacing (in.): 8-3/8 to 26-3/4 (OD)
Fork Width/Length (in.): 4 x 42
Service Range (in.): 2-9/16 to 63
Adjustable Leg Spacing (in.): 40-1/8 to 50 (ID)
Overall Mast Height (in.): 78-5/8
Required PSI: 80-100
