Aluminum Adjustable High Pressure Sodium Double Arm Loading Dock Light 60 In. Yellow

Aluminum Adjustable High Pressure Sodium Double Arm Loading Dock Light for Commercial Dock Access and Waterfront Operations, 60 in.
The dock loading light minimizes freight damage while expediting loading and unloading. Designed to provide uniform visibility inside trailers or around dock areas. This light offers much higher lumens/watt output and a very long lamp life. Low operating cost and can be used in damp locations. UL listed.
Product Status
Available Ships from Chicago, IL 60613 Non-Returnable
Key Features
  • Minimize freight damage while expediting loading and unloading operations
  • Provide uniform visibility inside trailers or around dock areas
  • Light offers much higher lumens/watt output and a very long lamp life
  • Low operating cost and can be used in damp locations
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Testing Certificate   90 Days Warranty
Product Data

Core Data

Assembled Weight 19 lbs
Assembled Size 9.5"W x 37.25"L x 12.5"H
Total Ship Weight 19 lbs
Package 1 Size 10"W x 32"D x 8"H
Color / Finish Yellow
Freight Type Parcel

Additional Attributes

Voltage/Phase 115/1
Arm Length (in.) 60
Extended Length (in.) 66-3/4
Arm Type Double Arm Adjustable
Bulb Type High Pressure Sodium
Lamp Head Polycarbonate
Extended Product Details

Marketing Specs.

MFG Model # (Series)
AALLS-60
Product Name
Aluminum Adjustable High Pressure Sodium Double Arm Loading Dock Light 60 In. Yellow
UPC
691215000642
GTIN
00691215000642
Taxonomy 1
Lighting & Fans
Taxonomy 2
Work Lights & Accessories
Taxonomy 3
Work Lights
Taxonomy 4
Corded
Assembled Depth (in.)
37.25
Assembled Width(in.)
9.5
Assembled Height(in.)
12.5
Assembled Weight(lbs.)
19
Color/Finish
Yellow
Material
Aluminum
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
US
Approval Drawing Required? Y/N
N
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
32
Package Width (in.)
10
Package Height (in.)
8
Package Weight (in.)
19
Subclass
8
Freight Class
85
NMFC Code
Lamps or Lighting Fixtures
NMFC Number
109700
LTL Freight
Parcel
UNSPSC
39112004
HTSUS Number
8530.80.0000
USMCA HS
8530.80
Origin Criterion
B
Certification Indicator
A
ECCN
EAR99
US Shipping Point
Chicago, IL
Supplier Postal Code
60613
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
90 Days Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
N
Returnable? Y/N
N
California Prop 65 Compliant?
No

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: AALLS-60

AALLS-60

Aluminum Adjustable High Pressure Sodium Double Arm Loading Dock Light 60 In. Yellow

The dock loading light minimizes freight damage while expediting loading and unloading. Designed to provide uniform visibility inside trailers or around dock areas. This light offers much higher lumens/watt output and a very long lamp life. Low operating cost and can be used in damp locations. UL listed.

  • Minimize freight damage while expediting loading and unloading operations
  • Provide uniform visibility inside trailers or around dock areas
  • Light offers much higher lumens/watt output and a very long lamp life
  • Low operating cost and can be used in damp locations

Core Data

Assembled Weight: 19 Assembled Size: 9.5"W x 37.25"L x 12.5"H Color: Yellow
Total Ship Weight: 19 Package 1 Size: 10"W x 32"D x 8"H Freight: Parcel

Specifications

Voltage/Phase: 115/1
Arm Length (in.): 60
Extended Length (in.): 66-3/4
Arm Type: Double Arm Adjustable
Bulb Type: High Pressure Sodium
Lamp Head: Polycarbonate
