Steel Pneumatic Scissor Lift Table 39-1/2 In. x 19-3/4 In. x 29-1/2 In. 400 Lb. Capacity Blue

Pneumatic Air Lift Table for Ergonomic Load Lifting and Workstation Positioning, 400 lb. Capacity with 39-1/2 in. x 19-3/4 in. x 29-1/2 in.
The Pneumatic scissor lift table works great in many environmentally sensitive applications. The table can be used anywhere utilizing only shop air. Air actuator valve is included and no electrical power or hydraulic oil required.
Product Status
Available QuickShip
Key Features
  • Lift table for ergonomic work in many environmentally sensitive applications
  • The table utilizes shop air so that it can be used anywhere
  • Air actuator valve uses no electrical power or hydraulic oil which is useful in a clean environment
  • Foot control pedal included for maximum control in environmentally sensitive applications
Quick Actions

Product Resources

Image Gallery View product images Dimensions Open dimensioned image Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Hydraulic Oil SDS   1 Year Warranty
Product Data

Core Data

Assembled Weight 214 lbs
Assembled Size 19.75"W x 39.5"L x 29.5"H
Total Ship Weight 234 lbs
Package 1 Size 40"W x 48"D x 32"H
Color / Finish Blue
Freight Type LTL Palletized

Additional Attributes

Uniform Capacity (lb.) 400
Platform Width (in.) 19-1/2
Platform Length (in.) 39-1/2
Platform Material Chrome Plated
Lowered Height (in.) 11-1/4
Raised Height (in.) 29-1/2
Foot Control Height (in.) 10
Lift Loaded/Unloaded (sec.) 13.31/8.31
Lower Loaded/Unloaded (sec.) 6.41/9.00
Cylinder Bore Diameter (mm) 32
PSI Required for Operation 70-90
Extended Product Details

Marketing Specs.

MFG Model # (Series)
AT-20
Product Name
Steel Pneumatic Scissor Lift Table 39-1/2 In. x 19-3/4 In. x 29-1/2 In. 400 Lb. Capacity Blue
UPC
691215319829
GTIN
00691215319829
Taxonomy 1
Material Handling
Taxonomy 2
Lifting Equipment
Taxonomy 3
Lifters / Tilters
Taxonomy 4
Scissor Lift Table
Taxonomy 5
Pneumatic
Assembled Depth (in.)
39.5
Assembled Width(in.)
19.75
Assembled Height(in.)
29.5
Assembled Weight(lbs.)
214
Color/Finish
Blue
Material
Steel
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
CN
Approval Drawing Required? Y/N
N
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
48
Package Width (in.)
40
Package Height (in.)
32
Package Weight (in.)
234
Subclass
17
Freight Class
175
NMFC Code
Conveyors Elevators or Lifts NOI
NMFC Number
120700
LTL Freight
LTL Palletized
UNSPSC
24101617
HTSUS Number
8428.90.0390
USMCA HS
8428.90
Origin Criterion
NO
Certification Indicator
NO
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
Yes
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
1 Year Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: AT-20

AT-20

Steel Pneumatic Scissor Lift Table 39-1/2 In. x 19-3/4 In. x 29-1/2 In. 400 Lb. Capacity Blue

The Pneumatic scissor lift table works great in many environmentally sensitive applications. The table can be used anywhere utilizing only shop air. Air actuator valve is included and no electrical power or hydraulic oil required.

  • Lift table for ergonomic work in many environmentally sensitive applications
  • The table utilizes shop air so that it can be used anywhere
  • Air actuator valve uses no electrical power or hydraulic oil which is useful in a clean environment
  • Foot control pedal included for maximum control in environmentally sensitive applications

Core Data

Assembled Weight: 214 Assembled Size: 19.75"W x 39.5"L x 29.5"H Color: Blue
Total Ship Weight: 234 Package 1 Size: 40"W x 48"D x 32"H Freight: LTL Palletized

Specifications

Uniform Capacity (lb.): 400
Platform Width (in.): 19-1/2
Platform Length (in.): 39-1/2
Platform Material: Chrome Plated
Lowered Height (in.): 11-1/4
Raised Height (in.): 29-1/2
Foot Control Height (in.): 10
Lift Loaded/Unloaded (sec.): 13.31/8.31
Lower Loaded/Unloaded (sec.): 6.41/9.00
Cylinder Bore Diameter (mm): 32
PSI Required for Operation: 70-90
