Steel Additional Removable Bollard Base 10-1/2 In. x 10-1/4 In. x 2 In. Silver

Steel Bollard Base for Warehouse Traffic Control and Collision Protection, 10-1/2 in. x 10-1/4 in. x 2 in.
The removable bollard base is perfect for around structures. The base plate adds extra strength to the bollard unit by securing the bollard structure in place. The bright color lends itself to discernment from long distances in areas of heavy foot traffic. To use, simply slip the bottom of the bollard into the base, position the detachable handle in place, and attach to surface by utilizing the pre-drilled mounting holes.
Product Status
Available QuickShip
Key Features
  • Bollard base bolts to your cement floor for easy bollard removal or replacement
  • Bollards can be used both indoors and outdoors to protect work areas, racking and personnel
  • Guard is easily inserted into base plate then secured in place
  • Padlock maybe added to prevent unauthorized removal
Quick Actions

Product Resources

Image Gallery View product images Dimensions Open dimensioned image Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Approval Drawing   Testing Certificate   Removable Steel Bollards series BOL-R Manual   Steel Safety Bollard BOL series   90 Days Warranty
Product Data

Core Data

Assembled Weight 12 lbs
Assembled Size 10.25"W x 10.5"L x 2"H
Total Ship Weight 13 lbs
Package 1 Size 14"W x 13"D x 6"H
Color / Finish Silver
Freight Type Parcel

Additional Attributes

Bolt Holes (qty.) 4
Usable Width (in.) 6-3/4
Padlock Slotted Hole Diameter (in.) 3/8 x 5/8
Extended Product Details

Marketing Specs.

MFG Model # (Series)
BOL-RF-BASE
Product Name
Steel Additional Removable Bollard Base 10-1/2 In. x 10-1/4 In. x 2 In. Silver
UPC
691215075831
GTIN
00691215075831
Taxonomy 1
Material Handling
Taxonomy 2
Loading Dock Equipment
Taxonomy 3
Safety Equipment
Taxonomy 4
Bollards
Taxonomy 5
Accessories
Taxonomy 6
Bases
Assembled Depth (in.)
10.5
Assembled Width(in.)
10.25
Assembled Height(in.)
2
Assembled Weight(lbs.)
12
Color/Finish
Silver
Material
Steel
Option? Y/N
Y
Sell UOM
EA-Each
Country Of Origin
CN
Approval Drawing Required? Y/N
N
Assembly
Assembled
Compatible Products
BOL-RF-24-4.5, BOL-RF-24-5.5, BOL-RF-36-4.5, BOL-RF-36-5.5, BOL-RF-42-4.5, BOL-RF-42-5.5, BOL-RF-48-4.5, BOL-RF-48-5.5

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
13
Package Width (in.)
14
Package Height (in.)
6
Package Weight (in.)
13
Subclass
9
Freight Class
70
NMFC Code
Hardware Group brackets hangers or supports
NMFC Number
95190
LTL Freight
Parcel
UNSPSC
30241504
HTSUS Number
7308.90.9590
USMCA HS
7308.90
Origin Criterion
NO
Certification Indicator
NO
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
90 Days Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Yes
Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: BOL-RF-BASE

BOL-RF-BASE

Steel Additional Removable Bollard Base 10-1/2 In. x 10-1/4 In. x 2 In. Silver

The removable bollard base is perfect for around structures. The base plate adds extra strength to the bollard unit by securing the bollard structure in place. The bright color lends itself to discernment from long distances in areas of heavy foot traffic. To use, simply slip the bottom of the bollard into the base, position the detachable handle in place, and attach to surface by utilizing the pre-drilled mounting holes.

  • Bollard base bolts to your cement floor for easy bollard removal or replacement
  • Bollards can be used both indoors and outdoors to protect work areas, racking and personnel
  • Guard is easily inserted into base plate then secured in place
  • Padlock maybe added to prevent unauthorized removal

Core Data

Assembled Weight: 12 Assembled Size: 10.25"W x 10.5"L x 2"H Color: Silver
Total Ship Weight: 13 Package 1 Size: 14"W x 13"D x 6"H Freight: Parcel

Specifications

Bolt Holes (qty.): 4
Usable Width (in.): 6-3/4
Padlock Slotted Hole Diameter (in.): 3/8 x 5/8
