Steel Mechanical Scissor Cart with Hand Crank 17-3/4 In. x 27-1/2 In. 330 Lb. Capacity Blue/Silver

Manual Scissor Cart for Ergonomic Load Lifting and Workstation Positioning, 330 lb. Capacity with 17-3/4 in. x 27-1/2 in.
When lifting and transporting are both essential, look no further than the mechanical scissor cart. The centrally located hand crank allows the user to raise and lower the platform to a more exact level. A large platform gives the ability to load items in a variety of sizes. Since the platform can be maneuvered to a specific height, the unit can be positioned to best fit the users needs for a more ergonomically friendly experience. Poly casters are included for a smooth roll on a variety of surfaces.
Product Status
Out of Stock QuickShip
Key Features
  • Hand crank for precise positioning
  • Large capacity for lifting objects both big and small
  • Powder coated finish for long term toughness
  • Smooth steel top minimizes abrasions
Quick Actions

Product Resources

Image Gallery View product images Dimensions Open dimensioned image Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Approval Drawing   Testing Certificate   1 Year Warranty
Product Data

Core Data

Assembled Weight 85 lbs
Assembled Size 17.75"W x 37"L x 28.75"H
Total Ship Weight 124 lbs
Package 1 Size 41"W x 49"D x 20"H
Color / Finish Blue
Freight Type LTL Palletized

Additional Attributes

Uniform Capacity (lb.) 330
Platform Width (in.) 17-3/4
Platform Length (in.) 27-1/2
Lowered Height (in.) 13-3/4
Raised Height (in.) 28-3/4
Operation Type Hand Crank
Caster Quantity/Diameter/Width (in.) (4) 5 x 1-1/2
Caster Type Poly
Caster Quantity/Type (2) Rigid, (2) Swivel w/brake
Overall Length Without Handle (in.) 29-3/4
Shaft Stick-Out From Table Edge Without Handle (in.) 2-1/8
Fame Thickness (in.) 1
Scissor Frame Width (in.) 9-5/8
Overall Scissor Frame Width (in.) 16
Caster Mount Length (in.) 3-1/8
Caster Mount Width (in.) 2-3/8
Cranks to Raise Platform 192.5
Extended Product Details

Marketing Specs.

MFG Model # (Series)
CART-330-M
Product Name
Steel Mechanical Scissor Cart with Hand Crank 17-3/4 In. x 27-1/2 In. 330 Lb. Capacity Blue/Silver
UPC
691215326384
GTIN
00691215326384
Taxonomy 1
Material Handling
Taxonomy 2
Lifting Equipment
Taxonomy 3
Lifters / Tilters
Taxonomy 4
Scissor Carts
Taxonomy 5
Manual
Assembled Depth (in.)
37
Assembled Width(in.)
17.75
Assembled Height(in.)
28.75
Assembled Weight(lbs.)
85
Color/Finish
Blue
Material
Steel
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
CN
Approval Drawing Required? Y/N
N
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
49
Package Width (in.)
41
Package Height (in.)
20
Package Weight (in.)
124
Subclass
18
Freight Class
92.5
NMFC Code
Conveyors Elevators or Lifts NOI
NMFC Number
120700
LTL Freight
LTL Palletized
UNSPSC
24101501
HTSUS Number
8427.90.0090
USMCA HS
8427.90
Origin Criterion
NO
Certification Indicator
NO
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
1 Year Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: CART-330-M

CART-330-M

Steel Mechanical Scissor Cart with Hand Crank 17-3/4 In. x 27-1/2 In. 330 Lb. Capacity Blue/Silver

When lifting and transporting are both essential, look no further than the mechanical scissor cart. The centrally located hand crank allows the user to raise and lower the platform to a more exact level. A large platform gives the ability to load items in a variety of sizes. Since the platform can be maneuvered to a specific height, the unit can be positioned to best fit the users needs for a more ergonomically friendly experience. Poly casters are included for a smooth roll on a variety of surfaces.

  • Hand crank for precise positioning
  • Large capacity for lifting objects both big and small
  • Powder coated finish for long term toughness
  • Smooth steel top minimizes abrasions

Core Data

Assembled Weight: 85 Assembled Size: 17.75"W x 37"L x 28.75"H Color: Blue
Total Ship Weight: 124 Package 1 Size: 41"W x 49"D x 20"H Freight: LTL Palletized

Specifications

Uniform Capacity (lb.): 330
Platform Width (in.): 17-3/4
Platform Length (in.): 27-1/2
Lowered Height (in.): 13-3/4
Raised Height (in.): 28-3/4
Operation Type: Hand Crank
Caster Quantity/Diameter/Width (in.): (4) 5 x 1-1/2
Caster Type: Poly
Caster Quantity/Type: (2) Rigid, (2) Swivel w/brake
Overall Length Without Handle (in.): 29-3/4
Shaft Stick-Out From Table Edge Without Handle (in.): 2-1/8
Fame Thickness (in.): 1
Scissor Frame Width (in.): 9-5/8
Overall Scissor Frame Width (in.): 16
Caster Mount Length (in.): 3-1/8
Caster Mount Width (in.): 2-3/8
Cranks to Raise Platform: 192.5
