Plastic Double Drum Lock 55 Gallon 3 In. x 23-1/8 In. x 3 In. Black/White

Double Drum Lock Plastic for Opening, Moving, and Handling Industrial Drums and Barrels, 3 in. x 23-1/8 in. x 3 in.
A double drum lock is the perfect solution to keeping the contents of drums safe and secure. This plastic double drum lock is a simple design that utilizes the bungs of the drum to position threaded cylinders for lockout. Once the cylinder lockouts are tightened and in the correct position a rod can then be inserted through one of the port holes of both cylinders. The rod design has an open ended frame for allowing padlock to pass through for complete lockout. Padlock not included.
Product Status
Available QuickShip
Key Features
  • Plastic drum caps
  • Prevent unauthorized access to drum contents
  • Simple screw drum lock placement
  • Rod is pre-drilled with a padlock hole
Quick Actions

Product Resources

Image Gallery View product images Dimensions Open dimensioned image Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Approval Drawing   Testing Certificate   DDL-55-AL/BRS/P Double Drum Lock   30 Days Warranty
Product Data

Core Data

Assembled Weight 2 lbs
Assembled Size 23.125"W x 3"L x 3"H
Total Ship Weight 3 lbs
Package 1 Size 4"W x 24"D x 4"H
Color / Finish Black / White
Freight Type Parcel

Additional Attributes

Accomodates Drum Size 55 Gallon
Extended Product Details

Marketing Specs.

MFG Model # (Series)
DDL-55-P
Product Name
Plastic Double Drum Lock 55 Gallon 3 In. x 23-1/8 In. x 3 In. Black/White
UPC
691215346023
GTIN
00691215346023
Taxonomy 1
Material Handling
Taxonomy 2
Drum & Barrel Parts / Accessories
Taxonomy 3
Accessories
Taxonomy 4
Locks
Assembled Depth (in.)
3
Assembled Width(in.)
23.125
Assembled Height(in.)
3
Assembled Weight(lbs.)
2
Color/Finish
Black / White
Material
Plastic
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
US
Approval Drawing Required? Y/N
N
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
24
Package Width (in.)
4
Package Height (in.)
4
Package Weight (in.)
3
Subclass
7
Freight Class
92.5
NMFC Code
LOCKS
NMFC Number
18260
LTL Freight
Parcel
UNSPSC
24101901
HTSUS Number
3926.90.9989
USMCA HS
3926.90
Origin Criterion
B
Certification Indicator
D
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
30 Days Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: DDL-55-P

DDL-55-P

Plastic Double Drum Lock 55 Gallon 3 In. x 23-1/8 In. x 3 In. Black/White

A double drum lock is the perfect solution to keeping the contents of drums safe and secure. This plastic double drum lock is a simple design that utilizes the bungs of the drum to position threaded cylinders for lockout. Once the cylinder lockouts are tightened and in the correct position a rod can then be inserted through one of the port holes of both cylinders. The rod design has an open ended frame for allowing padlock to pass through for complete lockout. Padlock not included.

  • Plastic drum caps
  • Prevent unauthorized access to drum contents
  • Simple screw drum lock placement
  • Rod is pre-drilled with a padlock hole

Core Data

Assembled Weight: 2 Assembled Size: 23.125"W x 3"L x 3"H Color: Black / White
Total Ship Weight: 3 Package 1 Size: 4"W x 24"D x 4"H Freight: Parcel

Specifications

Accomodates Drum Size: 55 Gallon
