Steel DC Powered Drum Lifter/Rotator/Transport 61 In. x 36-1/4 In. x 88 In. 550 Lb. Capacity Black/Yellow

DC-Powered Portable Drum Lifter/rotator/transporter for Opening, Moving, and Handling Industrial Drums and Barrels, 550 lb. Capacity with 61 in. x 36-1/4 in. x 88 in., Black & Yellow
This portable Drum Lifter/rotator/transporter features a DC powered rotation mechanism which provides rotation of the drum. The DC powered mechanism raises and lowers the drum (on-board charger standard). For use with steel and fiber drums.
Product Status
Available QuickShip
Key Features
  • Unique design works with 55 gallon drums
  • Caster style rolls smoothly when loaded
  • Solid steel construction offers long lasting rugged use
  • Drum lifter design lifts, rotates & transports drums easily
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Approval Drawing   Testing Certificate   DRUM-LRT Portable Drum Lifter Rotator Transporter   Label Page PDF   Hydraulic Oil SDS   90 Days Warranty
Product Data

Core Data

Assembled Weight 752 lbs
Assembled Size 36.25"W x 61"L x 88"H
Total Ship Weight 826 lbs
Package 1 Size 41"W x 67"D x 86"H
Color / Finish Black & Yellow
Freight Type LTL Palletized

Additional Attributes

Uniform Capacity (lb.) 550
Vertical Raised Height (in.) 62
Horizontal (Dump) Raised Height (in.) 67
Drum Size 55-gallon
Drum Diameter (in.) 24
Drum Type Steel, Fiber
Rotation Mechanism (volts) 24
Rotation (degree) 360
Raise and Lower Mechanism (volts) 24
Operates DC Power
Battery Quantity 2
Leg Type Fixed
Caster Quantity 4
Caster Material Mold-on-Rubber
Caster Diameter (in.) 7
Caster Width (in.) 2

Battery Information

Battery Depth 14
Battery Width 14
Battery Height 10
Battery Weight 112
Battery Freight Class 70
Battery NMFC Number 60680
Battery NMFC Description Batteries or Cells
Lithium Battery Configuration C -- Contained In
Extended Product Details

Marketing Specs.

MFG Model # (Series)
DRUM-LRT-DC-II
Product Name
Steel DC Powered Drum Lifter/Rotator/Transport 61 In. x 36-1/4 In. x 88 In. 550 Lb. Capacity Black/Yellow
UPC
691215086103
GTIN
00691215086103
Taxonomy 1
Material Handling
Taxonomy 2
Drum & Barrel Parts / Accessories
Taxonomy 3
Accessories
Taxonomy 4
Drum Rotators / Carriers
Taxonomy 5
Electric
Assembled Depth (in.)
61
Assembled Width(in.)
36.25
Assembled Height(in.)
88
Assembled Weight(lbs.)
752
Color/Finish
Black & Yellow
Material
Steel
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
CN
Approval Drawing Required? Y/N
N
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
67
Package Width (in.)
41
Package Height (in.)
86
Package Weight (in.)
826
Subclass
6
Freight Class
200
NMFC Code
Cars, Lift Trucks or Vehicles,áNOI, not designed for general highway use,
NMFC Number
190235
LTL Freight
LTL Palletized
UNSPSC
24101903
HTSUS Number
8428.90.0390
USMCA HS
8428.90
Origin Criterion
NO
Certification Indicator
NO
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
Yes
Batteries Included?
Yes
Battery Weight (lbs.)
112
Battery Freight Class
70
Battery NMFC Number
60680
Battery NMFC Description
Batteries or Cells
Lithium Battery Configuration
C -- Contained In

Warranty

Warranty
Yes
Manufactuer Warranty
90 Days Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: DRUM-LRT-DC-II

DRUM-LRT-DC-II

Steel DC Powered Drum Lifter/Rotator/Transport 61 In. x 36-1/4 In. x 88 In. 550 Lb. Capacity Black/Yellow

This portable Drum Lifter/rotator/transporter features a DC powered rotation mechanism which provides rotation of the drum. The DC powered mechanism raises and lowers the drum (on-board charger standard). For use with steel and fiber drums.

  • Unique design works with 55 gallon drums
  • Caster style rolls smoothly when loaded
  • Solid steel construction offers long lasting rugged use
  • Drum lifter design lifts, rotates & transports drums easily

Core Data

Assembled Weight: 752 Assembled Size: 36.25"W x 61"L x 88"H Color: Black & Yellow
Total Ship Weight: 826 Package 1 Size: 41"W x 67"D x 86"H Freight: LTL Palletized

Specifications

Uniform Capacity (lb.): 550
Vertical Raised Height (in.): 62
Horizontal (Dump) Raised Height (in.): 67
Drum Size: 55-gallon
Drum Diameter (in.): 24
Drum Type: Steel, Fiber
Rotation Mechanism (volts): 24
Rotation (degree): 360
Raise and Lower Mechanism (volts): 24
Operates: DC Power
Battery Quantity: 2
Leg Type: Fixed
Caster Quantity: 4
Caster Material: Mold-on-Rubber
Caster Diameter (in.): 7
Caster Width (in.): 2
