Metal Beam E-Socket Support For Standard 2 In. x 4 In. Wood Board Gold

Beam Socket Support for Securing Cargo on Trucks and Trailers, 2 in. x 4 in.
An optional beam E-socket that supports the end of a wood board. Works on a standard 2 x 4.
Product Status
Available QuickShip
Key Features
  • Quick connection for immediate
  • Lightweight for simple handling
  • Features durable construction for added strength and long life
  • Use in industrial applications for optimal results
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Testing Certificate   Cargo Bars Manual   30 Days Warranty
Product Data

Core Data

Assembled Weight 2 lbs
Assembled Size 1.875"W x 3.375"L x 4.375"H
Total Ship Weight 2 lbs
Package 1 Size 5"W x 7"D x 3"H
Color / Finish Gold
Freight Type Parcel

Additional Attributes

Clamping Diameter (in) 1.5
Opening Height (in) 4.375
Opening Width (in) 1.625
Frame Clip Design Without Barbs
Material Thickness (in) .125
Extended Product Details

Marketing Specs.

MFG Model # (Series)
E-CLIP-W
Product Name
Metal Beam E-Socket Support For Standard 2 In. x 4 In. Wood Board Gold
UPC
691215060332
GTIN
00691215060332
Taxonomy 1
Hardware
Taxonomy 2
Fasteners
Taxonomy 3
Pins, Rings & Clips
Taxonomy 4
Clips
Taxonomy 5
Frame Clips
Assembled Depth (in.)
3.375
Assembled Width(in.)
1.875
Assembled Height(in.)
4.375
Assembled Weight(lbs.)
2
Color/Finish
Gold
Material
Steel
Option? Y/N
Y
Sell UOM
EA-Each
Country Of Origin
CN
Approval Drawing Required? Y/N
N
Assembly
Assembled
Compatible Products
STRAP-12-RE, STRAP-16-CE, STRAP-16-RE, STRAP-27-RH, STRAP-27-FH, STRAP-6-RTO

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
7
Package Width (in.)
5
Package Height (in.)
3
Package Weight (in.)
2
Subclass
1
Freight Class
65
NMFC Code
Block Brace Brackets Straps or Devices
NMFC Number
24100
LTL Freight
Parcel
UNSPSC
24102101
HTSUS Number
7326.90.8688
USMCA HS
7326.90
Origin Criterion
NO
Certification Indicator
NO
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
30 Days Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: E-CLIP-W

E-CLIP-W

Metal Beam E-Socket Support For Standard 2 In. x 4 In. Wood Board Gold

An optional beam E-socket that supports the end of a wood board. Works on a standard 2 x 4.

  • Quick connection for immediate
  • Lightweight for simple handling
  • Features durable construction for added strength and long life
  • Use in industrial applications for optimal results

Core Data

Assembled Weight: 2 Assembled Size: 1.875"W x 3.375"L x 4.375"H Color: Gold
Total Ship Weight: 2 Package 1 Size: 5"W x 7"D x 3"H Freight: Parcel

Specifications

Clamping Diameter (in): 1.5
Opening Height (in): 4.375
Opening Width (in): 1.625
Frame Clip Design: Without Barbs
Material Thickness (in): .125
