Plastic Electric Drum Pump 115 Volt 7-1/2 In. x 4-1/4 In. x 8 In. Silver

Electric Barrel Pump for Opening, Moving, and Handling Industrial Drums and Barrels, 115 Volt
This electric drum pump will reduce the time required to dispense or transfer liquids. It allows you to move fluid easily and efficiently with a continuous run rating.
Product Status
Available QuickShip
Key Features
  • Electric drum pump moves fluid easily and efficiently with a continuous run rating
  • Ideal for drum handling situations for maximum efficiency
  • Features durable construction for added strength and long life
  • Use in industrial applications for optimal results
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Testing Certificate   30 Days Warranty
Product Data

Core Data

Assembled Weight 18 lbs
Assembled Size 4.25"W x 7.5"L x 8"H
Total Ship Weight 20 lbs
Package 1 Size 11"W x 53"D x 7"H
Color / Finish Silver
Freight Type Parcel

Additional Attributes

Drum Pump Design Pneumatic
Maximum Viscosity Rating (SSU) 1950
Pump Body Material Stainless Steel
Pump Motor 115V Single Phase AC
Motor Horsepower (HP) 0.25
Dispensing Volume 400 CPS
Hose Included? Yes
Hose Length (in.) 78-3/4
Self Priming? Yes
Automatic Overflow Protection? No
Bung Size (in.) 2
Inlet Size (in.) 3/16
Outlet Size (in.) 3/16
Rated Flow (GPM) 22.75
Compatible Drum Sizes 15 to 55
Extended Product Details

Marketing Specs.

MFG Model # (Series)
EDP
Product Name
Plastic Electric Drum Pump 115 Volt 7-1/2 In. x 4-1/4 In. x 8 In. Silver
UPC
691215016711
GTIN
00691215016711
Taxonomy 1
Material Handling
Taxonomy 2
Drum & Barrel Parts / Accessories
Taxonomy 3
Accessories
Taxonomy 4
Drum Pumps
Assembled Depth (in.)
7.5
Assembled Width(in.)
4.25
Assembled Height(in.)
8
Assembled Weight(lbs.)
18
Color/Finish
Silver
Material
Plastic/Stainless Steel
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
TW
Approval Drawing Required? Y/N
N
Assembly
Assembly required

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
53
Package Width (in.)
11
Package Height (in.)
7
Package Weight (in.)
20
Freight Class
85
NMFC Code
Pumps power NOI loose or in packages
NMFC Number
128000
LTL Freight
Parcel
UNSPSC
40151529
HTSUS Number
8413.91.9099
USMCA HS
8413.91
Origin Criterion
NO
Certification Indicator
NO
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
30 Days Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: EDP

EDP

Plastic Electric Drum Pump 115 Volt 7-1/2 In. x 4-1/4 In. x 8 In. Silver

This electric drum pump will reduce the time required to dispense or transfer liquids. It allows you to move fluid easily and efficiently with a continuous run rating.

  • Electric drum pump moves fluid easily and efficiently with a continuous run rating
  • Ideal for drum handling situations for maximum efficiency
  • Features durable construction for added strength and long life
  • Use in industrial applications for optimal results

Core Data

Assembled Weight: 18 Assembled Size: 4.25"W x 7.5"L x 8"H Color: Silver
Total Ship Weight: 20 Package 1 Size: 11"W x 53"D x 7"H Freight: Parcel

Specifications

Drum Pump Design: Pneumatic
Maximum Viscosity Rating (SSU): 1950
Pump Body Material: Stainless Steel
Pump Motor: 115V Single Phase AC
Motor Horsepower (HP): 0.25
Dispensing Volume: 400 CPS
Hose Included?: Yes
Hose Length (in.): 78-3/4
Self Priming?: Yes
Automatic Overflow Protection?: No
Bung Size (in.): 2
Inlet Size (in.): 3/16
Outlet Size (in.): 3/16
Rated Flow (GPM): 22.75
Compatible Drum Sizes: 15 to 55
