Steel Fully Powered Electric Pallet Truck 20 In. x 47 In. 2,600 Lb. Capacity Black

Ergonomic Electric Pallet Truck for Moving Loads Through Warehouses and Production Areas, 2,600 lb. Capacity with 20 in. x 47 in.
A fully powered electric pallet truck provides a quick and easy solution in close-fitting areas. The narrow fork design is perfect for half and quarter sized pallets, making it a reliable resource in warehouses and trailers. Reinforced welded forks with adjustable tie-rods provide long term service. High-torque drive & lift motor endures heavy-duty jobs. Ergonomic handle features easy to operate throttle with infinite adjustment of forward and reverse speeds, lift/lower controls, proprietary safety-enhancing emergency reverse function, and horn.
Product Status
Available QuickShip
Key Features
  • Quick performing raise and lower buttons
  • 24V DC drive
  • Poly on steel casters
  • 3.1 To 7.625" service range
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Documents

PDFs & Product Files

  360 Image   Hydraulic Oil SDS   Valve-Regulated Lead Acid Battery Series SDS   1 Year Warranty
Product Data

Core Data

Assembled Weight 315 lbs
Assembled Size 25.25"W x 65"L x 46"H
Total Ship Weight 574 lbs
Package 1 Size 45"W x 70"D x 58"H
Color / Finish Black
Freight Type LTL Palletized

Additional Attributes

Overall Fork Width (in.) 15
Overall Fork Length (in.) 40
Uniform Capacity (lbs.) 2,600
Handle Length (in.) 46
Battery Weight (lbs.) 28.5
Battery size (in.) 7.75x6.5x6.69
Load Center (in.) 9
Individual Fork Width (in.) 5.3125
Space Between Forks (in.) 4.3

Battery Information

Battery Depth 11
Battery Width 14
Battery Height 10
Battery Weight 98
Battery Freight Class 60
Battery NMFC Number 60700
Battery NMFC Description Gel batteries on unit
Lithium Battery Configuration C -- Contained In
Extended Product Details

Marketing Specs.

MFG Model # (Series)
EPT-1540-26
Product Name
Steel Fully Powered Electric Pallet Truck 20 In. x 47 In. 2,600 Lb. Capacity Black
UPC
691215093835
GTIN
00691215093835
Taxonomy 1
Material Handling
Taxonomy 2
Pallet Jacks and Lifts
Assembled Depth (in.)
65
Assembled Width(in.)
25.25
Assembled Height(in.)
46
Assembled Weight(lbs.)
315
Color/Finish
Black
Material
Steel
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
CN
Approval Drawing Required? Y/N
N
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
70
Package Width (in.)
45
Package Height (in.)
58
Package Weight (in.)
574
Subclass
6
Freight Class
200
NMFC Code
Cars, Lift Trucks or Vehicles,áNOI, not designed for general highway use,
NMFC Number
190235
LTL Freight
LTL Palletized
UNSPSC
24101505
HTSUS Number
8427.90.0090
USMCA HS
8427.90
Origin Criterion
NO
Certification Indicator
NO
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
Yes
MSDS? Yes/No
Yes
Batteries Included?
Yes
Battery Weight (lbs.)
98
Battery Freight Class
60
Battery NMFC Number
60700
Battery NMFC Description
Gel batteries on unit
Lithium Battery Configuration
C -- Contained In

Warranty

Warranty
Yes
Manufactuer Warranty
1 Year Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: EPT-1540-26

EPT-1540-26

Steel Fully Powered Electric Pallet Truck 20 In. x 47 In. 2,600 Lb. Capacity Black

A fully powered electric pallet truck provides a quick and easy solution in close-fitting areas. The narrow fork design is perfect for half and quarter sized pallets, making it a reliable resource in warehouses and trailers. Reinforced welded forks with adjustable tie-rods provide long term service. High-torque drive & lift motor endures heavy-duty jobs. Ergonomic handle features easy to operate throttle with infinite adjustment of forward and reverse speeds, lift/lower controls, proprietary safety-enhancing emergency reverse function, and horn.

  • Quick performing raise and lower buttons
  • 24V DC drive
  • Poly on steel casters
  • 3.1 To 7.625" service range

Core Data

Assembled Weight: 315 Assembled Size: 25.25"W x 65"L x 46"H Color: Black
Total Ship Weight: 574 Package 1 Size: 45"W x 70"D x 58"H Freight: LTL Palletized

Specifications

Overall Fork Width (in.): 15
Overall Fork Length (in.): 40
Uniform Capacity (lbs.): 2,600
Handle Length (in.): 46
Battery Weight (lbs.): 28.5
Battery size (in.): 7.75x6.5x6.69
Load Center (in.): 9
Individual Fork Width (in.): 5.3125
Space Between Forks (in.): 4.3
