Steel Fork Truck Hook Base 32 In. Length 4,000 Lb. Capacity Blue

Fork Truck Hook Base for Overhead Load Lifting and Controlled Positioning, 4,000 lb. Capacity with 32 in. Length
Convert your fork truck into a tow truck for moving trailers and other portable equipment using this Fork Truck base. Simple design slides onto forks and secures into place with pin style tine locks. Welded steel construction with powder coat blue finish.
Product Status
Available QuickShip
Key Features
  • Base converts fork truck into a tow truck for moving trailers
  • Fork truck is ideal for other portable equipment
  • Slides onto forks and secures into place with pin style tine locks for optimal use
  • Steel construction with powder coat finish for strength and durability
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Approval Drawing   Testing Certificate   Fork Truck Base series HOOK-BASE Manual   Label Page PDF   90 Days Warranty
Product Data

Core Data

Assembled Weight 88 lbs
Assembled Size 30.6875"W x 40"L x 6"H
Total Ship Weight 139 lbs
Package 1 Size 40"W x 48"D x 12"H
Color / Finish Blue
Freight Type LTL Palletized

Additional Attributes

Uniform Capacity (lb.) 4,000
Minimum Fork Length (in.) 36
Length to Center of Ball (in.) 32-3/8
Usable Fork Width/Height (in.) 5 x 2
Overall Height (in.) 6
Overall Width (in.) 30-11/16
Overall Length (in.) 40
Lost Load (lbs.) 87.85
Extended Product Details

Marketing Specs.

MFG Model # (Series)
HOOK-BASE-32
Product Name
Steel Fork Truck Hook Base 32 In. Length 4,000 Lb. Capacity Blue
UPC
691215051491
GTIN
00691215051491
Taxonomy 1
Material Handling
Taxonomy 2
Forklift Attachments
Taxonomy 3
Hook Plates
Assembled Depth (in.)
40
Assembled Width(in.)
30.6875
Assembled Height(in.)
6
Assembled Weight(lbs.)
88
Color/Finish
Blue
Material
Steel
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
US
Approval Drawing Required? Y/N
N
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
48
Package Width (in.)
40
Package Height (in.)
12
Package Weight (in.)
139
Subclass
7
Freight Class
92.5
NMFC Code
Lift Truck Attachments: Fork arms, fingers/tine, s
NMFC Number
193100
LTL Freight
LTL Palletized
UNSPSC
25181708
HTSUS Number
8428.90.0390
USMCA HS
8428.90
Origin Criterion
B
Certification Indicator
D
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
90 Days Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: HOOK-BASE-32

HOOK-BASE-32

Steel Fork Truck Hook Base 32 In. Length 4,000 Lb. Capacity Blue

Convert your fork truck into a tow truck for moving trailers and other portable equipment using this Fork Truck base. Simple design slides onto forks and secures into place with pin style tine locks. Welded steel construction with powder coat blue finish.

  • Base converts fork truck into a tow truck for moving trailers
  • Fork truck is ideal for other portable equipment
  • Slides onto forks and secures into place with pin style tine locks for optimal use
  • Steel construction with powder coat finish for strength and durability

Core Data

Assembled Weight: 88 Assembled Size: 30.6875"W x 40"L x 6"H Color: Blue
Total Ship Weight: 139 Package 1 Size: 40"W x 48"D x 12"H Freight: LTL Palletized

Specifications

Uniform Capacity (lb.): 4,000
Minimum Fork Length (in.): 36
Length to Center of Ball (in.): 32-3/8
Usable Fork Width/Height (in.): 5 x 2
Overall Height (in.): 6
Overall Width (in.): 30-11/16
Overall Length (in.): 40
Lost Load (lbs.): 87.85
