Steel Variable Height Pail Dispenser 125 Lb. Capacity Blue and Yellow

Variable Height Pail Dispenser for Commercial and Industrial Pails & Pail Equipment Use, 125 lb. Capacity
Variable height pail dispenser provides several settings for dispensing five (5) gallon plastic or steel pails. Dispense by turning the hand cable winch. Steel construction with a baked-in powder-coated toughness.
Product Status
Available
Key Features
  • Provides settings for dispensing five (5) gallon plastic or steel pails
  • Dispense by turning the hand cable winch
  • Variable height pail dispenser provides several settings for dispensing
  • Use in industrial applications for optimal results
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Approval Drawing   Testing Certificate   LLW, LLPW, ALLW, ALLPW Light Load Lifters Use and Maintenance Manual   Variable Height Pail Dispenser   Label Page PDF   90 Days Warranty
Product Data

Core Data

Assembled Weight 105 lbs
Assembled Size 26"W x 35.875"L x 71.25"H
Total Ship Weight 139 lbs
Package 1 Size 48"W x 40"D x 72"H
Color / Finish Blue (Frame), Yellow (Cradle)
Freight Type LTL Palletized

Additional Attributes

Uniform Capacity (lb.) 125
Accepts Pail Diameter (in.) 11
Angle Setting (qty.) 24
Pour Height Lowered (in.) 1
Pour Height Raised (in.) 52
Cradle Height Lowered (in.) 6
Cradle Height Raised (in.) 62-3/4
Raised Height (in.) 71-1/4
Rotation Angle (deg.) 24
Rotation (deg.) 135
(2) Rear Swivel Casters with Total Lock Diameter (in.) 4
Rear Caster Material Poly-on-Poly
(2) Front Steel Roller Diameter (in.) 2
Extended Product Details

Marketing Specs.

MFG Model # (Series)
LLW-PAILD-100
Product Name
Steel Variable Height Pail Dispenser 125 Lb. Capacity Blue and Yellow
UPC
691215088794
GTIN
00691215088794
Taxonomy 1
Material Handling
Taxonomy 2
Drum & Barrel Parts / Accessories
Taxonomy 3
Tools
Taxonomy 4
Drum Dumper
Assembled Depth (in.)
35.875
Assembled Width(in.)
26
Assembled Height(in.)
71.25
Assembled Weight(lbs.)
105
Color/Finish
Blue (Frame), Yellow (Cradle)
Material
Steel
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
US
Approval Drawing Required? Y/N
N
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
40
Package Width (in.)
48
Package Height (in.)
72
Package Weight (in.)
139
Subclass
1
Freight Class
175
NMFC Code
Lift trucks hand including pallet jacks
NMFC Number
189240
LTL Freight
LTL Palletized
UNSPSC
24100000
HTSUS Number
8428.90.0390
USMCA HS
8428.90
Origin Criterion
B
Certification Indicator
D
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
90 Days Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: LLW-PAILD-100

LLW-PAILD-100

Steel Variable Height Pail Dispenser 125 Lb. Capacity Blue and Yellow

Variable height pail dispenser provides several settings for dispensing five (5) gallon plastic or steel pails. Dispense by turning the hand cable winch. Steel construction with a baked-in powder-coated toughness.

  • Provides settings for dispensing five (5) gallon plastic or steel pails
  • Dispense by turning the hand cable winch
  • Variable height pail dispenser provides several settings for dispensing
  • Use in industrial applications for optimal results

Core Data

Assembled Weight: 105 Assembled Size: 26"W x 35.875"L x 71.25"H Color: Blue (Frame), Yellow (Cradle)
Total Ship Weight: 139 Package 1 Size: 48"W x 40"D x 72"H Freight: LTL Palletized

Specifications

Uniform Capacity (lb.): 125
Accepts Pail Diameter (in.): 11
Angle Setting (qty.): 24
Pour Height Lowered (in.): 1
Pour Height Raised (in.): 52
Cradle Height Lowered (in.): 6
Cradle Height Raised (in.): 62-3/4
Raised Height (in.): 71-1/4
Rotation Angle (deg.): 24
Rotation (deg.): 135
(2) Rear Swivel Casters with Total Lock Diameter (in.): 4
Rear Caster Material: Poly-on-Poly
(2) Front Steel Roller Diameter (in.): 2
