Steel Drum Truck Cradle With Semi-Steel Wheels 20-1/16 In. x 23-11/16 In. x 60-5/8 In. 1000 Lb. Capacity Yellow

Drum Truck Cradle with Semi-steel Wheels for Opening, Moving, and Handling Industrial Drums and Barrels, 1,000 lb. Capacity with 20-1/16 in. x 23-11/16 in. x 60-5/8 in.
This multi-purpose drum truck/cradle is one of the most versatile drum trucks in the industry. This innovative product allows the operator to easily tip back the truck in order to transport drums ergonomically on four (4) wheels. Unit doubles as a drum cradle for storage and dispensing all in one. This unique design also allows the operator to place drums and retrieve off of a pallet. Standard with a wheeled undercarriage that positions the drum horizontally for drainage or storage. An integral self-storing bung wrench is standard. This attractive feature not only opens numerous drums, but helps to keep the drum snug on the truck. Powder coat finish.
Product Status
Available QuickShip Non-Returnable
Key Features
  • Multi-purpose drum truck/cradle is versatile for ideal operation
  • Tip back the truck in order to transport drums ergonomically on four wheels
  • Features a wheeled undercarriage that positions the drum for drainage or storage
  • Includes an integral self-storing bung wrench
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Approval Drawing   Testing Certificate   Label Page PDF   90 Days Warranty
Product Data

Core Data

Assembled Weight 128 lbs
Assembled Size 23.6875"W x 20.0625"L x 60.625"H
Total Ship Weight 134 lbs
Package 1 Size 40"W x 64"D x 26"H
Color / Finish Yellow
Freight Type LTL Palletized

Additional Attributes

Uniform Capacity (lb.) 1,000
Semi-Steel Wheel Quantity/Diameter/Width (in.) (2) 10 x 2-1/2
Poly on Poly Wheel Quantity/Diameter/Width (in.) (2) 6 x 2
Poly on Poly Swivel Caster Quantity/Diameter/Width (in.) (2) 3 x 1-1/4
Drain Height (in.) 12-13/16
Tip Angle (degree) 3
Accepts 55-gallon steel, plastic or fiber drums
Nose plate Depth (in.) 4
Nose plate Width (in.) 1-1/2
Nose plate Thickness (in.) 1/2
Number of Vertical Supports (quantity) 2
Usable Width (in.) 17-1/16
Extended Product Details

Marketing Specs.

MFG Model # (Series)
RDBT-SS
Product Name
Steel Drum Truck Cradle With Semi-Steel Wheels 20-1/16 In. x 23-11/16 In. x 60-5/8 In. 1000 Lb. Capacity Yellow
UPC
691215052931
GTIN
00691215052931
Taxonomy 1
Material Handling
Taxonomy 2
Hand Trucks & Dollies
Taxonomy 3
Drum Movers
Taxonomy 4
Drum Truck
Assembled Depth (in.)
20.0625
Assembled Width(in.)
23.6875
Assembled Height(in.)
60.625
Assembled Weight(lbs.)
128
Color/Finish
Yellow
Material
Steel
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
US
Approval Drawing Required? Y/N
N
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
64
Package Width (in.)
40
Package Height (in.)
26
Package Weight (in.)
134
Subclass
1
Freight Class
150
NMFC Code
Carts Barrel Hand SU on wheels or KD flat
NMFC Number
188760
LTL Freight
LTL Palletized
UNSPSC
24101900
HTSUS Number
8716.80.5090
USMCA HS
8716.80
Origin Criterion
B
Certification Indicator
D
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
90 Days Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
N
Returnable? Y/N
N
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: RDBT-SS

RDBT-SS

Steel Drum Truck Cradle With Semi-Steel Wheels 20-1/16 In. x 23-11/16 In. x 60-5/8 In. 1000 Lb. Capacity Yellow

This multi-purpose drum truck/cradle is one of the most versatile drum trucks in the industry. This innovative product allows the operator to easily tip back the truck in order to transport drums ergonomically on four (4) wheels. Unit doubles as a drum cradle for storage and dispensing all in one. This unique design also allows the operator to place drums and retrieve off of a pallet. Standard with a wheeled undercarriage that positions the drum horizontally for drainage or storage. An integral self-storing bung wrench is standard. This attractive feature not only opens numerous drums, but helps to keep the drum snug on the truck. Powder coat finish.

  • Multi-purpose drum truck/cradle is versatile for ideal operation
  • Tip back the truck in order to transport drums ergonomically on four wheels
  • Features a wheeled undercarriage that positions the drum for drainage or storage
  • Includes an integral self-storing bung wrench

Core Data

Assembled Weight: 128 Assembled Size: 23.6875"W x 20.0625"L x 60.625"H Color: Yellow
Total Ship Weight: 134 Package 1 Size: 40"W x 64"D x 26"H Freight: LTL Palletized

Specifications

Uniform Capacity (lb.): 1,000
Semi-Steel Wheel Quantity/Diameter/Width (in.): (2) 10 x 2-1/2
Poly on Poly Wheel Quantity/Diameter/Width (in.): (2) 6 x 2
Poly on Poly Swivel Caster Quantity/Diameter/Width (in.): (2) 3 x 1-1/4
Drain Height (in.): 12-13/16
Tip Angle (degree): 3
Accepts: 55-gallon steel, plastic or fiber drums
Nose plate Depth (in.): 4
Nose plate Width (in.): 1-1/2
Nose plate Thickness (in.): 1/2
Number of Vertical Supports (quantity): 2
Usable Width (in.): 17-1/16
