Steel Narrow Manual Rough Terrain Stacker 59 In. Raised Height 1,500 Lb. Capacity Yellow/Black

Narrow Manual Rough Terrain Stacker for Moving Loads Through Warehouses and Production Areas, 1,500 lb. Capacity with 59 in. Raised Height
A rough terrain stacker is capable of going where other stackers can't. The narrow design provides precise movement in condensed areas. A handle pump design lifts and lowers, without the need for mechanical power. Just a simple hydraulic action leads the forks up or down to the desired height. The rubber tires provide stability when traversing rough or uneven surfaces. Baked in yellow powder coat finish.
Product Status
Out of Stock QuickShip Non-Returnable
Key Features
  • 59" raised height
  • Wide, straddle based design
  • Adjustable forks
  • Full height wire-mesh back guard
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Approval Drawing   Testing Certificate   Hydraulic Oil SDS   90 Days Warranty
Product Data

Core Data

Assembled Weight 530 lbs
Assembled Size 38"W x 61.8125"L x 79.3125"H
Total Ship Weight 565 lbs
Package 1 Size 40"W x 64"D x 85"H
Color / Finish Yellow & Black
Freight Type LTL Palletized

Additional Attributes

Uniform Capacity (lb.) 1,500
Raised Height (in.) 59
Lowered Height (in.) 3-1/8
Fork Size (in.) 4 x 40-1/8
Handle Length (in) 43
Handle Diameter (in.) 1-1/8
Rubber Drive Wheel (2) 2-3/4"x 9-7/8"
Rubber Front Wheel (2) 3-1/2"x 15"
Power/Operation Hydraulic Hand Pump
Extended Product Details

Marketing Specs.

MFG Model # (Series)
RT-NMS-60-AF
Product Name
Steel Narrow Manual Rough Terrain Stacker 59 In. Raised Height 1,500 Lb. Capacity Yellow/Black
UPC
691215376143
GTIN
00691215376143
Taxonomy 1
Material Handling
Taxonomy 2
Pallet Jacks and Lifts
Assembled Depth (in.)
61.8125
Assembled Width(in.)
38
Assembled Height(in.)
79.3125
Assembled Weight(lbs.)
530
Color/Finish
Yellow & Black
Material
Steel
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
CN
Approval Drawing Required? Y/N
Y
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
64
Package Width (in.)
40
Package Height (in.)
85
Package Weight (in.)
565
Subclass
1
Freight Class
175
NMFC Code
Lift trucks hand including pallet jacks
NMFC Number
189240
LTL Freight
LTL Palletized
UNSPSC
24101606
HTSUS Number
8428.90.0390
USMCA HS
8428.90
Origin Criterion
No
Certification Indicator
No
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
90 Days Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
N
Returnable? Y/N
N
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: RT-NMS-60-AF

RT-NMS-60-AF

Steel Narrow Manual Rough Terrain Stacker 59 In. Raised Height 1,500 Lb. Capacity Yellow/Black

A rough terrain stacker is capable of going where other stackers can't. The narrow design provides precise movement in condensed areas. A handle pump design lifts and lowers, without the need for mechanical power. Just a simple hydraulic action leads the forks up or down to the desired height. The rubber tires provide stability when traversing rough or uneven surfaces. Baked in yellow powder coat finish.

  • 59" raised height
  • Wide, straddle based design
  • Adjustable forks
  • Full height wire-mesh back guard

Core Data

Assembled Weight: 530 Assembled Size: 38"W x 61.8125"L x 79.3125"H Color: Yellow & Black
Total Ship Weight: 565 Package 1 Size: 40"W x 64"D x 85"H Freight: LTL Palletized

Specifications

Uniform Capacity (lb.): 1,500
Raised Height (in.): 59
Lowered Height (in.): 3-1/8
Fork Size (in.): 4 x 40-1/8
Handle Length (in): 43
Handle Diameter (in.): 1-1/8
Rubber Drive Wheel: (2) 2-3/4"x 9-7/8"
Rubber Front Wheel: (2) 3-1/2"x 15"
Power/Operation: Hydraulic Hand Pump
