Steel Counter Balanced Power Lift Single Spindle With Rollers 2-3/8" Attachment 200 Lb. Capacity Gray

Counter Balance Attachments for Moving Loads Through Warehouses and Production Areas, 200 lb. Capacity
The spindle attachment is designed of a strong construction for lifting rolls of material and other hollow cylinder objects. A simple installation allows the user to obtain immediate use and diminishes the chore of bending and lifting heavy objects. With included rollers, the items quickly and easily slide on and off of the spindle with ease.
Product Status
Available
Key Features
  • Powder coated gray
  • Low maintenance design
  • Pre-drilled mounting holes
  • Secured directly to stacker mast
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Testing Certificate   90 Days Warranty
Product Data

Core Data

Assembled Weight 25 lbs
Assembled Size 9"W x 26"L x 12"H
Total Ship Weight 27 lbs
Package 1 Size 12"W x 28"D x 15"H
Color / Finish GRAY
Freight Type Parcel

Additional Attributes

Uniform Capacity (Lbs.) 200
Spindle Type Single With Rollers
Roller Size (In.) 2.375
Extended Product Details

Marketing Specs.

MFG Model # (Series)
STA-ATT-SPINR-25
Product Name
Steel Counter Balanced Power Lift Single Spindle With Rollers 2-3/8" Attachment 200 Lb. Capacity Gray
UPC
691215375306
GTIN
00691215375306
Taxonomy 1
Material Handling
Taxonomy 2
Forklifts
Taxonomy 3
Parts & Accessories
Taxonomy 4
Masts & Accessories
Taxonomy 5
Attachments
Assembled Depth (in.)
26
Assembled Width(in.)
9
Assembled Height(in.)
12
Assembled Weight(lbs.)
25
Color/Finish
GRAY
Material
STEEL
Option? Y/N
Y
Sell UOM
EA-Each
Country Of Origin
CN
Approval Drawing Required? Y/N
N
Assembly
Assembled
Compatible Products
S-CB-NM-60, DRLT-CB-54-MDML, DRLT-CB-54-MDPL, DRLT-CB-54-PDPL, SL-63-AA, SL-118-AA, SL-137-AA, SL-150-AA, S-101-AA-DM, S-118-AA-DM, S-125-AA-DM, S-150-AA-DM, S3-118-AA, S3-125-AA, S3-43-AA, S3-62-AA, S-CB-118, S-CB-62, RT-EPT-2-48, RT-EPT-3-24, RT-EPT-3-48, RT-S-35-AF, RT-S-62-AF

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
28
Package Width (in.)
12
Package Height (in.)
15
Package Weight (in.)
27
Subclass
6
Freight Class
100
NMFC Code
Lift Truck Attachments: Fork arms, fingers/tine, steel
NMFC Number
193100
LTL Freight
Parcel
UNSPSC
24101600
HTSUS Number
8431.31.0060
USMCA HS
8431.31
Origin Criterion
NO
Certification Indicator
NO
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
90 Days Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: STA-ATT-SPINR-25

STA-ATT-SPINR-25

Steel Counter Balanced Power Lift Single Spindle With Rollers 2-3/8" Attachment 200 Lb. Capacity Gray

The spindle attachment is designed of a strong construction for lifting rolls of material and other hollow cylinder objects. A simple installation allows the user to obtain immediate use and diminishes the chore of bending and lifting heavy objects. With included rollers, the items quickly and easily slide on and off of the spindle with ease.

  • Powder coated gray
  • Low maintenance design
  • Pre-drilled mounting holes
  • Secured directly to stacker mast

Core Data

Assembled Weight: 25 Assembled Size: 9"W x 26"L x 12"H Color: GRAY
Total Ship Weight: 27 Package 1 Size: 12"W x 28"D x 15"H Freight: Parcel

Specifications

Uniform Capacity (Lbs.): 200
Spindle Type: Single With Rollers
Roller Size (In.): 2.375
