Aluminum Dock Board Steel Curb 60 In. x 48 In. 10,000 Lb. Capacity Silver

Aluminum Truck Dock Board for Trailer Loading, Dock Access, and Material Transfer, 10,000 lb. Capacity with 60 in. x 48 in.
The Aluminum truck dock board with steel safety curbs is designed for portability and safety. The deck is made of tough high strength aluminum tread plate. The edges are beveled for smooth entry and exit. Safety curbs are coated yellow and are constructed of steel with cast tapered ends. Steel legs are bolted on for increased durability. Canted locking legs for easier truck portability. Manufactured in compliance with OSHA. The capacity is based upon the heaviest type of equipment used plus the maximum load carried times the single axle rating of total load. Dynamic loading, driver tendencies, speed and frequency of use must be considered. When using three-wheeled fork trucks order dock board with capacity at least four-times the lifting capacity of fork truck. The width of the dock board should be at least fifteen (15) inches wider than the load or equipment passing between the curbs. If the load does not pass between curbs, but is elevated above, add fifteen (15) inches to overall width of equipment.
Product Status
Available QuickShip
Key Features
  • High-strength aluminum tread plate material is durable yet lightweight
  • Zinc-plated locking legs are within OSHA compliance
  • Beveled entrance and exit edges allow for smoother transition
  • Heavy-duty steel curbs are painted yellow and bolted to deck plate for safer use
Quick Actions

Product Resources

Image Gallery View product images Dimensions Open dimensioned image Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Approval Drawing   Testing Certificate   360 Image   AHTD, TAS Dockboards Manual   Label Page PDF   90 Days Warranty
Product Data

Core Data

Assembled Weight 129 lbs
Assembled Size 60"W x 48"L x 12.5625"H
Total Ship Weight 129 lbs
Package 1 Size 60"W x 48"D x 14"H
Color / Finish Silver
Freight Type LTL Loose

Additional Attributes

Uniform Capacity (lb.) 10000
Height Difference at 11 degree/19 percent (in.) 7
Location of Legs From Beveled Edge (in.) 11
Bend Degree 11
Bend Distance from Beveled Edge (in.) 8-13/16
Usable Width (in.) 56
Usable Length (in.) 48
Plate Thickness (in.) 5/16
Curb Height (in.) 3-9/16
OSHA 1910.30(a)
ANSI MH 30.2
Extended Product Details

Marketing Specs.

MFG Model # (Series)
TAS-10-6048
Product Name
Aluminum Dock Board Steel Curb 60 In. x 48 In. 10,000 Lb. Capacity Silver
UPC
691215039321
GTIN
00691215039321
Taxonomy 1
Material Handling
Taxonomy 2
Loading Dock Equipment
Taxonomy 3
Dockboards & Accessories
Taxonomy 4
Dockboard
Assembled Depth (in.)
48
Assembled Width(in.)
60
Assembled Height(in.)
12.5625
Assembled Weight(lbs.)
129
Color/Finish
Silver
Material
Aluminum
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
US
Approval Drawing Required? Y/N
N
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
48
Package Width (in.)
60
Package Height (in.)
14
Package Weight (in.)
129
Subclass
1
Freight Class
100
NMFC Code
Ramps Dockboards freight loading not mechanical
NMFC Number
168720
LTL Freight
LTL Loose
UNSPSC
24101807
HTSUS Number
7610.90.0080
USMCA HS
7610.90
Origin Criterion
B
Certification Indicator
D
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
90 Days Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: TAS-10-6048

TAS-10-6048

Aluminum Dock Board Steel Curb 60 In. x 48 In. 10,000 Lb. Capacity Silver

The Aluminum truck dock board with steel safety curbs is designed for portability and safety. The deck is made of tough high strength aluminum tread plate. The edges are beveled for smooth entry and exit. Safety curbs are coated yellow and are constructed of steel with cast tapered ends. Steel legs are bolted on for increased durability. Canted locking legs for easier truck portability. Manufactured in compliance with OSHA. The capacity is based upon the heaviest type of equipment used plus the maximum load carried times the single axle rating of total load. Dynamic loading, driver tendencies, speed and frequency of use must be considered. When using three-wheeled fork trucks order dock board with capacity at least four-times the lifting capacity of fork truck. The width of the dock board should be at least fifteen (15) inches wider than the load or equipment passing between the curbs. If the load does not pass between curbs, but is elevated above, add fifteen (15) inches to overall width of equipment.

  • High-strength aluminum tread plate material is durable yet lightweight
  • Zinc-plated locking legs are within OSHA compliance
  • Beveled entrance and exit edges allow for smoother transition
  • Heavy-duty steel curbs are painted yellow and bolted to deck plate for safer use

Core Data

Assembled Weight: 129 Assembled Size: 60"W x 48"L x 12.5625"H Color: Silver
Total Ship Weight: 129 Package 1 Size: 60"W x 48"D x 14"H Freight: LTL Loose

Specifications

Uniform Capacity (lb.): 10000
Height Difference at 11 degree/19 percent (in.): 7
Location of Legs From Beveled Edge (in.): 11
Bend Degree: 11
Bend Distance from Beveled Edge (in.): 8-13/16
Usable Width (in.): 56
Usable Length (in.): 48
Plate Thickness (in.): 5/16
Curb Height (in.): 3-9/16
OSHA: 1910.30(a)
ANSI: MH 30.2
