Steel Manual Stacker Adjustable Forks/Legs 2,000 Lb. Capacity Black / Yellow

Adjustable Manual Pallet Stacker for Moving Loads Through Warehouses and Production Areas, 2,000 lb. Capacity
The manual stacker is designed to meet the most challenging tasks. Ideal for use in various workstation and workplace applications. Maintenance free and easy to use. The full height push handle allows for easy steering and excellent visibility through a welded mesh guard with an optional removable platform available. It features a heavy-duty mast and a unique winch design for easier and safer lifting. The lifting and lowering is completed by a manual hand pump operation. The two (2) rigid and two (2) swivel wheels with brakes make it easy for maneuvering. The unit features both adjustable forks and adjustable legs.
Product Status
Out of Stock QuickShip
Key Features
  • Stacker design meets the most challenging tasks
  • Unique design is maintenance free and easy to use
  • Full height push handle allows for easy steering
  • Manual design offers easier and safer lifting
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Documents

PDFs & Product Files

  Approval Drawing   Testing Certificate   360 Image   "OPERATION & SERVICE MANUAL MANUAL HAND PUMP STACKER MODEL: VHPS-2000-AA & VHPS-2000-FF"   Label Page PDF   1 Year Warranty
Product Data

Core Data

Assembled Weight 792 lbs
Assembled Size 57.875"W x 61.25"L x 78"H
Total Ship Weight 860 lbs
Package 1 Size 64"W x 67"D x 88"H
Color / Finish Black / Yellow
Freight Type LTL Palletized

Additional Attributes

Uniform Capacity (lb.) 2,000
Service Range (in.) 2-1/8 to 63
Fork Length (in.) 42-1/8
Fork Width (in.) 3-15/16
Adjustable Straddle Leg Range (in.) 38-3/16 to 50
Adjustable Fork Spacing Range (in.) 7-7/8 to 26-3/4
Mast Single
Operation Hand Pump
Rear Caster Quantity/Diameter/Width (in.) (2) 7 x 2
Rear Caster Type Swivel with Brake
Front Caster Quantity/Diameter/Width (in.) (2) 4 x 2-29/32
Front Caster Type Rigid
Horizontal Load Center (in.) 24
Pumps to Raise to Max Height (qty.) 74
Stroke per Pump (in.) 15/16
Time to Lower w/o Load (sec.) 18
Time to Lower w/ Load (sec.) 20
Overall Mast Height (in.) 78
Steering Wheel Size (in.) 7x2
Extended Product Details

Marketing Specs.

MFG Model # (Series)
VHPS-2000-AA
Product Name
Steel Manual Stacker Adjustable Forks/Legs 2,000 Lb. Capacity Black / Yellow
UPC
691215096171
GTIN
00691215096171
Taxonomy 1
Material Handling
Taxonomy 2
Lifting Equipment
Taxonomy 3
Lifters / Tilters
Taxonomy 4
Box Stacker
Taxonomy 5
Manual
Assembled Depth (in.)
61.25
Assembled Width(in.)
57.875
Assembled Height(in.)
78
Assembled Weight(lbs.)
792
Color/Finish
Black / Yellow
Material
Steel
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
CN
Approval Drawing Required? Y/N
N
Assembly
Assembled
Compatible Products
VHPS-DK, VHPS-AA-DRR-FK

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
67
Package Width (in.)
64
Package Height (in.)
88
Package Weight (in.)
860
Subclass
1
Freight Class
175
NMFC Code
Lift trucks hand including pallet jacks
NMFC Number
189240
LTL Freight
LTL Palletized
UNSPSC
24101606
HTSUS Number
8428.90.0390
USMCA HS
8428.90
Origin Criterion
NO
Certification Indicator
NO
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
1 Year Limited Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Prop 65 Warning

Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: VHPS-2000-AA

VHPS-2000-AA

Steel Manual Stacker Adjustable Forks/Legs 2,000 Lb. Capacity Black / Yellow

The manual stacker is designed to meet the most challenging tasks. Ideal for use in various workstation and workplace applications. Maintenance free and easy to use. The full height push handle allows for easy steering and excellent visibility through a welded mesh guard with an optional removable platform available. It features a heavy-duty mast and a unique winch design for easier and safer lifting. The lifting and lowering is completed by a manual hand pump operation. The two (2) rigid and two (2) swivel wheels with brakes make it easy for maneuvering. The unit features both adjustable forks and adjustable legs.

  • Stacker design meets the most challenging tasks
  • Unique design is maintenance free and easy to use
  • Full height push handle allows for easy steering
  • Manual design offers easier and safer lifting

Core Data

Assembled Weight: 792 Assembled Size: 57.875"W x 61.25"L x 78"H Color: Black / Yellow
Total Ship Weight: 860 Package 1 Size: 64"W x 67"D x 88"H Freight: LTL Palletized

Specifications

Uniform Capacity (lb.): 2,000
Service Range (in.): 2-1/8 to 63
Fork Length (in.): 42-1/8
Fork Width (in.): 3-15/16
Adjustable Straddle Leg Range (in.): 38-3/16 to 50
Adjustable Fork Spacing Range (in.): 7-7/8 to 26-3/4
Mast: Single
Operation: Hand Pump
Rear Caster Quantity/Diameter/Width (in.): (2) 7 x 2
Rear Caster Type: Swivel with Brake
Front Caster Quantity/Diameter/Width (in.): (2) 4 x 2-29/32
Front Caster Type: Rigid
Horizontal Load Center (in.): 24
Pumps to Raise to Max Height (qty.): 74
Stroke per Pump (in.): 15/16
Time to Lower w/o Load (sec.): 18
Time to Lower w/ Load (sec.): 20
Overall Mast Height (in.): 78
Steering Wheel Size (in.): 7x2
